The Model FP4700 Fiber Optic Temperature Sensors are designed for use in environments where high levels of electrical interference exist or where intrinsic safety is an issue. The FP4700 uses the temperature-dependent birefringence of a specially selected crystal as the temperature transduction mechanism. This crystal does not show thermal creep or aging as with some other fiber optic sensors.
Specifications
| Temperature Range¹ | (Nominal) −40°C to +80°C (High Temperature) −40°C to +250°C |
| Resolution | 0.1°C |
| Accuracy² | ±1.0°C |
| Response Time | 1.5 s typical |
| Operating Humidity Range | 0-100% |
| Length × Diameter | 50 × 4.8 mm (sensor) |
¹Other ranges available on request.
²Total accuracy over the full range including both signal conditioner and sensor errors. Higher accuracy available on request.
